How to Add Stick-to-Bottom Features to Shadcn ScrollArea for Better Chat Interfaces

When building modern chat applications, one of the most crucial UX patterns is ensuring the scroll area automatically sticks to the bottom as new messages arrive. Users expect to see the latest messages without manually scrolling down every time. While AI SDK's conversation components provide this functionality out of the box, they come with their own styling that doesn't always align with your design system.

The Challenge

I was working on a chat interface using shadcn/ui components to maintain design consistency across my application. The shadcn ScrollArea component provides beautiful, theme-aware scrollbars that integrate seamlessly with the overall design system. However, it lacks the stick-to-bottom functionality that's essential for chat interfaces.

The AI SDK conversation components do include this behaviour, but they come with stock scrollbars that don't match the polished aesthetic of shadcn components. This created a dilemma: sacrifice design consistency for functionality, or lose essential UX behavior for visual appeal.

The Solution: Hybrid Approach

Rather than choosing between design and functionality, I decided to extend the existing shadcn ScrollArea component to support both modes of operation:

📝 View the complete implementation on GitHub Gist

1. Default mode: Standard scrolling behaviour for general content

2. Stick-to-bottom mode: Automatic bottom-sticking for chat interfaces

This approach preserves the beautiful shadcn styling while adding the sophisticated scroll management needed for conversational UIs.

Implementation Strategy

1. Context-Based State Management

The first step was creating a React context to share scroll state across components:

interface ScrollAreaContextType {
  isAtBottom: boolean;
  isNearBottom: boolean;
  scrollToBottom: () => void;
}

This context provides three key pieces of information:

• Current scroll position relative to bottom

• Programmatic scroll control

• Near-bottom detection for UI optimisations

2. External Library Integration

I leveraged the use-stick-to-bottom library, which handles the complex scroll event management and position calculations. The challenge was integrating this library's refs with Radix UI's ScrollArea primitive:

const mergedScrollRef = useCallback(
  (node: HTMLDivElement | null) => {
    localContainerRef.current = node;

    if (!libScrollRef) return;
    if (typeof libScrollRef === "function") libScrollRef(node);
    else (libScrollRef as React.RefObject<HTMLDivElement | null>).current = node;
  },
  [libScrollRef],
);

This ref merging pattern ensures both the external library and our component maintain proper DOM references while avoiding conflicts.

3. Mode-Based Component Switching

The enhanced ScrollArea component now accepts a mode prop that determines behaviour:

function ScrollArea({ mode = "default", ...props }: ScrollAreaProps) {
  if (mode === "stick-to-bottom") {
    return <ScrollAreaBottomStick {...props} />;
  }

  return <StandardScrollArea {...props} />;
}

This preserves backward compatibility while adding new functionality.

4. Smart Scroll Button

The ScrollButton component demonstrates context usage by conditionally rendering based on scroll position:

function ScrollButton() {
  const { isAtBottom, scrollToBottom } = useScrollArea();

  return (
    !isAtBottom && (
      <Button onClick={scrollToBottom}>
        <ArrowDownIcon />
      </Button>
    )
  );
}

This provides users with an intuitive way to jump back to the latest messages when they've scrolled up to read history.

Key Technical Decisions

Ref Management Strategy

One of the trickiest aspects was properly forwarding refs between multiple layers:

• Radix UI ScrollArea needs refs for scroll event handling

• The stick-to-bottom library needs refs for position calculations

• Our component might need refs for additional functionality

The solution was a ref merging pattern that accommodates both function refs and object refs, ensuring compatibility across different ref patterns.

Performance Optimisation

The implementation includes several performance optimisations:

const values = useMemo(() => {
  return {
    isNearBottom,
    isAtBottom,
    scrollToBottom,
  };
}, [isAtBottom, scrollToBottom, isNearBottom]);

Context values are memoized to prevent unnecessary re-renders of child components, and scroll event handlers are optimised within the external library.

Error Boundaries

The useScrollArea hook includes proper error handling to prevent runtime errors when used incorrectly:

if (!context) {
  throw new Error(
    "useScrollArea must be used within a <ScrollArea mode='stick-to-bottom'>",
  );
}

This provides clear developer feedback and prevents silent failures.

Usage in Practice

The enhanced component maintains the same API as the original shadcn ScrollArea while adding new capabilities:

// Standard scrolling (unchanged behavior)
<ScrollArea className="h-96">
  <div>Regular content</div>
</ScrollArea>

// Chat interface with stick-to-bottom
<ScrollArea mode="stick-to-bottom" className="h-96">
  <div className="space-y-2">
    {messages.map(msg => <Message key={msg.id} {...msg} />)}
  </div>
  <ScrollButton />
</ScrollArea>

Results and Benefits

This solution delivers several key advantages:

Design Consistency: Maintains shadcn's beautiful scrollbar styling and theme integration across the entire application.

Enhanced UX: Provides smooth stick-to-bottom behaviour that users expect from modern chat interfaces.

Developer Experience: Offers a simple, intuitive API that doesn't break existing code while adding powerful new functionality.

Flexibility: The context system allows for custom scroll controls and behaviours beyond the basic ScrollButton.

Performance: Optimised ref handling and memoization ensure smooth performance even with frequent content updates.

Conclusion

Building great user interfaces often requires bridging the gap between design systems and specialised functionality. By extending shadcn's ScrollArea component rather than replacing it, we preserved the design consistency that makes shadcn valuable while adding the behavioural sophistication needed for modern chat interfaces.

This pattern—extending existing design system components with new modes—is broadly applicable. It allows teams to maintain design consistency while adapting components for specialised use cases, creating a more cohesive and polished user experience.

The result is a chat interface that looks native to your design system while providing the smooth, intuitive scrolling behaviour users expect from professional applications.
